APC Smart-UPS 2200VA RM 2U LCD 120V
APC Smart-UPS, 1980 Watts / 2200 VA,Input 120V / Output 120V, Interface Port USB, Rack Height 2 U

Over 20 million units sold - the UPS you can trust

APC award-winning Smart-UPS® is the most popular UPS in the world for servers, storage and networks. Trusted to protect critical data and equipment from power problems by supplying clean and reliable network-grade power. In addition to legendary reliability and manageability, Smart-UPS have extremely high efficiency at low, medium and high load levels making them ideal for today’s multi-core or virtualized servers that have varying load consumption. Available in a variety of form factors (tower, rack mount, rack/tower convertible) there is a model for every application and budget. Rack mounted Smart-UPS are ideal for powering Blade or density optimized servers in a distributed power protection environment as the primary or redundant protection. Smart-UPS® models have long been considered the benchmark for all network and server UPS's. Smart-UPS feature a 16-segment LED display, extended range automatic voltage regulation (AVR), and pure sine wave output on battery. Additional manageability options are available through the Smart-Slot interface, which is an internal slot for the installation of optional accessory cards. The extended run Smart-UPS XL has the capability to add external battery packs to scale runtime from minutes to hours typically needed for converged voice and data networks. The entry level Smart-UPS SC is an economical choice for small and medium businesses looking to protect small switches, networking devices and point-of-sale (POS) equipment.

SMT2200RM2U Feature Overview:

• Intuitive LCD interface - Provides clear and accurate information in multiple languages with the ability to configure the UPS locally with easy to use navigation keys.
• Predictive replace battery date - Dynamically provides the month and year when battery replacement is recommended to aide in long term maintenance planning.
• Green mode - Patent-pending operating mode that bypasses unused electrical components in good power conditions to achieve very high operating efficiency without sacrificing any protection.
• Energy meter -   Provides actual kilowatt hours of usage for energy conscious users.
• Wide Input Voltage Window - Saves your battery power for when you really need it - during power cuts!
• Outlet group control  - Turn on/off, reboot or shut down select outlet groups to save dispatching technicians to remote locations (for UPSs with switched outlet groups).
• Sequenced shutdown and restart - Configure select outlet groups to shut down and turn on in a pre-determined order (for UPSs with switched outlet groups).
• Audible alarms - Provide notification of changing flywheel conditions
• Pure sine wave output on battery - Simulates utility power to provide the highest degree of compatibility for active PFC (power factor corrected) servers and sensitive electronics.
• Single switched outlet group - Single outlet group that may be controlled separately from the UPS for discrete reboot of hung devices, sequenced on/off and non-critical load shedding.
• Battery failure notification - Provides early-warning fault analysis on batteries enabling timely preventive maintenance
• Sequenced start-up - Power on select outlet groups in a defined sequence.
• High online efficiency - Reduces utlility costs, generates less heat.
• Cold-start capable - Provides temporary battery power when the utility power is out.
• Serial Connectivity -   Use any Home Automation network to monitor and control the S20 through its RS-232 serial port. For information on how to communicate with the S20, see APC's Application Note #102. Crestron and AMX installers should visit their respective websites for information on how to integrate the S20 into those networks.
• Hot-swappable batteries - Ensures clean, uninterrupted power to protected equipment while batteries are being replaced
• Disconnected battery notification - Warns when a battery is not available to provide backup power.
• Automatic self-test - Periodic battery self-test ensures early detection of a battery that needs to be replaced.
• Automatic restart of loads after UPS shutdown - Automatically starts up the connected equipment upon the return of utility power.
• Adjustable voltage-transfer points - Maximizes useful battery life by widening the input voltage window or tightening the output voltage regulation.
• Adjustable voltage sensitivity - Provides the ability to adapt the UPS for optimal performance in specific power environments or generator applications.
• Audible alarms - Provides notification of changing utility power and UPS conditions.
• User-replaceable batteries - Increases availability by allowing a trained user to perform upgrades and replacements of the batteries reducing Mean Time to Repair (MTTR)
• Serial Connectivity - Provides management of the UPS via a serial port.
• USB connectivity - Provides management of the UPS via a USB port (not available on all models).
• Temperature-compensated battery charging - Prolongs battery life by regulating the charge voltage according to battery temperature.
• Boost and Trim Automatic Voltage Regulation (AVR) - Gives higher application availability by correcting low and high voltage conditions without using the battery.
• Intelligent battery management - Maximizes battery performance, life, and reliability through intelligent, precision charging.
• Safety-agency approved - Ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment.
• Network manageable - Provides remote management of the UPS over the network.
• Frequency and voltage regulation - Gives higher application availability by correcting poor frequency and voltage conditions without using the battery.
• Adjustable voltage sensitivity - Provides the ability to adapt the Power Conditioner for optimal performance in specific power environments or generator applications.
• Predicitive failure notification - Provides early-warning fault analysis ensuring proactive component replacement.
