APC Smart-UPS On-Line Series

A versatile UPS developed for the harshest power conditions in the world.

Smart-UPS On-Line provides high density, true double-conversion on-line power protection for servers, voice / data networks, medical labs, and light industrial applications. Capable of supporting loads from 1 to 20kVA in a rack/tower convertible form, the Smart-UPS On-Line is available from 2U to 12U. Recent family extensions at 15 and 20kVA enable support of power hungry blade servers or heavily loaded equipment racks. When business-critical systems require runtime in hours, not minutes, Smart-UPS On-Line can be configured with matching battery packs to comply with aggressive runtime demands. The included PowerChute management software provides unattended graceful shutdown of network operating systems. All models 5kVA and above include an integrated Network Management Card for remote management (optional on models below 5 kVA). The entire Smart-UPS On-Line family provides value to customers with demanding power environments, including very wide input voltage window, extremely tight output voltage regulation, frequency regulation, internal bypass, and input power factor correction.

Smart-UPS On-Line Series - 120V Output / 120V Input
SURTA1000RMXL2U - APC Smart-UPS RT 1000VA RM 120V	SURTA1500RMXL2U - APC Smart-UPS RT 1500VA RM 120V	SURTA1500RMXL2U-NC - APC Smart-UPS RT 1500VA RM 120V with Network Card
SRT1000XLA - APC Smart-UPS SRT 1000VA 120V	SRT2200XLA - APC Smart-UPS SRT 2200VA 120V
Smart-UPS On-Line Series - 120V, 208V Output / 208V Input
SURTD5000RMXLP3U - APC Smart-UPS RT 5000VA RM 208V to 208/120V	SURTD6000RMXLP3U - APC Smart-UPS RT 6000VA RM 208V to 208/120V	SURT10KRMXL6U-TF5 - APC Smart-UPS RT 10KVA RM 208V w/ (2) 208V to 120V 2U Step-Down Transformer
SURT15KRMXLT-TF5 - APC Smart-UPS RT 15KVA RM 208V, 208V/120V 5KVA Step-Down Transformer	SURT20KRMXLT-TF5 - APC Smart-UPS RT 20KVA RM 208V, 208V/120V 5KVA Step-Down Transformer	SURT20KRMXLT-1TF10K - APC Smart-UPS RT 20KVA RM 208V, 208V/120V 10KVA Step-Down Transformer
SURT15KRMXLT-1TF10K - APC Smart-UPS RT 15KVA RM 208V, 208V/120V 10KVA Step-Down Transformer
Smart-UPS On-Line Series - 208V Output / 208V Input
SURT15KRMXLT - APC Smart-UPS RT 15kVA RM 208V	SURT20KRMXLT - APC Smart-UPS RT 20kVA RM 208V

Features & Benefits:

Availability
Automatic internal bypass	Supplies utility power to the connected loads in the event of a UPS overload condition or fault.
Scalable runtime	Allows additional run time to be quickly added as needed.
Intelligent battery management	Maximizes battery performance, life, and reliability through intelligent, precision charging.
Hot-swappable batteries	Ensures clean, uninterrupted power to protected equipment while batteries are being replaced
Automatic restart of loads after UPS shutdown	Automatically starts up the connected equipment upon the return of utility power.
Temperature-compensated battery charging	Prolongs battery life by regulating the charge voltage according to battery temperature.
Manageability
Network manageable	Provides remote management of the UPS over the network.
InfraStruXure Manager compatible	Enables centralized management via the APC InfraStruXure® Manager.
SmartSlot	Customize UPS capabilities with management cards.
LED status indicators	Quickly understand unit and power status with visual indicators.
Serial Connectivity	Provides management of the UPS via a serial port.
Adaptability
Plug-and-Play external batteries	Ensures clean, uninterrupted power to the loads when adding extra runtime to the UPS.
Rack/Tower convertible	Protects the initial investment in the UPS when migrating from tower to rack-mount environment.
Flash-upgradeable firmware	Install maintenance releases of firmware remotely using FTP.
Serviceability
User-replaceable batteries	Increases availability by allowing a trained user to perform upgrades and replacements of the batteries reducing Mean Time to Repair (MTTR)
Automatic self-test	Periodic battery self-test ensures early detection of a battery that needs to be replaced.
Predictive failure notification	Provides early-warning fault analysis ensuring proactive component replacement.
Disconnected battery notification	Warns when a battery is not available to provide backup power.
Audible alarms	Provides notification of changing utility power and UPS conditions.
Protection
Frequency and voltage regulation	Gives higher application availability by correcting poor frequency and voltage conditions without using the battery.
Power conditioning	Protects connected loads from surges, spikes, lightning, and other power disturbances.
Input power factor correction	Minimizes installation costs by enabling the use of smaller generators and cabling.
Generator compatible	Ensures clean, uninterrupted power to the loads in the event of an extended power outage.
Cold-start capable	Provides temporary battery power when the utility power is out.
Resettable circuit breakers	Easy recovery from overloads; no need to replace a fuse.
Safety-agency approved	Ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment. UL, FCC, CE, C-Tick approvals.

Runtime Chart:

Click here to view the Smart-UPS On-Line Runtime Chart. (pop-up window)
